Aluminum-Clad Steel Overhead Ground Wire
Specified by electric utilities for use on transmission lines as ground / shield wires
Ideal for marine or industrial zones where corrosion is a concern
Preferred option for transmission lines near coastal mines
Application
The covered aluminum steel wire for compression, internationally known as Alumoweld or ACS, is a wire of high resistance whose cover is carried through an extrusion process, that adheres the aluminum by pressure and heat. Once the covering process is finished, the wire is drawn until its final diameter without any alteration in the aluminum steel ratio.
Manufacture of Overhead Bare Conductor, OPGW, Ground Wire,Overhead Ground wire, Messenger wire, Guy wire, Formed wire for protecting, Terminating and Splicing Transmission and Distribution lines,Shield wire Protecting Transmission lines against lightning damage fence, barber wire and hardware. Aluminum-Clad steel Wire and Strand is used by Power Utilities as well as Formed Wire and Optical Ground Wire Manufacturers.
Standards
ASTM B416-American Standard
DIN 48201-German Standards
IEC 61232-International Electrotechnical Commission International Standards
ASTM B502-93-American Standard of Aluminum Clad Steel Wires
AS 1222.2-92-Australia Standard of Aluminum Clad Wires
ASTM B 415-02 1, Tensile Requirement
Code Number | Area | No.of Wires | Diameter | Weight | Rated Strength | Max.D.C. Resistance at 20℃ | |
| Wire | Cond. | ||||||
| mm2 | mm | mm | kg/km | kN | Ω/km | ||
| 3 x 5AWG | 50.32 | 3 | 4.62 | 9.96 | 334.1 | 54.42 | 1.6990 |
| 3 x 6AWG | 39.00 | 3 | 4.11 | 8.87 | 265.0 | 45.74 | 2.1420 |
| 3x7AWG | 31.65 | 3 | 3.67 | 7.90 | 210.1 | 38.36 | 2.7010 |
| 3 x 8AWG | 25.10 | 3 | 3.26 | 7.03 | 166.7 | 32.06 | 3.4060 |
| 3 x 9AWG | 19.90 | 3 | 2.91 | 6.26 | 132.2 | 25.43 | 4.2940 |
| 3x10AWG | 15.78 | 3 | 2.59 | 5.58 | 104.8 | 20.16 | 5.4150 |
| 7 x 5AWG | 117.40 | 7 | 4.62 | 13.90 | 781.1 | 120.27 | 0.7426 |
| 7 x 6AWG | 93.10 | 7 | 4.11 | 12.40 | 619.5 | 101.14 | 0.9198 |
| 7x7AWG | 73.87 | 7 | 3.67 | 11.00 | 491.1 | 84.81 | 1.1600 |
| 7x8AWG | 58.56 | 7 | 3.26 | 9.78 | 389.6 | 70.88 | 1.4630 |
| 7 x 9AWG | 46.44 | 7 | 2.91 | 8.71 | 308.9 | 56.20 | 1.8440 |
| 7x10AWG | 36.83 | 7 | 2.59 | 7.76 | 245.1 | 44.58 | 2.3250 |
| 7x11AWG | 29.21 | 7 | 2.30 | 6.91 | 194.4 | 35.35 | 2.9320 |
| 7x12AWG | 23.16 | 7 | 2.05 | 6.16 | 154.2 | 28.03 | 3.6970 |
| 19x5AWG | 318.70 | 19 | 4.62 | 23.10 | 2129.0 | 326.39 | 0.2698 |
| 19x6AWG | 252.70 | 19 | 4.11 | 20.60 | 1688.0 | 274.55 | 0.3402 |
| 19x7AWG | 200.40 | 19 | 3.67 | 18.30 | 1339.0 | 230.18 | 0.4290 |
| 19x8AWG | 158.90 | 19 | 3.26 | 16.30 | 1062.0 | 192.41 | 0.5409 |
| 19x9AWG | 126.10 | 19 | 2.91 | 14.50 | 842.0 | 152.58 | 0.6821 |
| 19x10AWG | 99.96 | 19 | 2.59 | 12.90 | 667.7 | 121.00 | 0.8601 |
| 37 x 5AWG | 620.60 | 37 | 4.62 | 32.30 | 4170.0 | 635.43 | 0.1394 |
| 37 x 6AWG | 492.20 | 37 | 4.11 | 28.80 | 3307.0 | 534.85 | 0.1757 |
| 37 x 7AWG | 390.30 | 37 | 3.67 | 25.70 | 2623.0 | 448.09 | 0.2216 |
| 37 x 8AWG | 309.50 | 37 | 3.26 | 22.90 | 2080.0 | 374.67 | 0.2794 |
| 37 x 9AWG | 245.50 | 37 | 2.91 | 20.30 | 1649.0 | 279.11 | 0.3523 |
| 37x10AWG | 194.70 | 37 | 2.59 | 17.90 | 1308.0 | 235.61 | 0.4443 |
| Code Number | Area | No. of wires | Diameters(mm) | Weight | Rated Strength | DC Resistance | |
| mm2 | mm2 | wire | conductor | kg/km | kN | ohm/km | |
| 25 | 24.25 | 7 | 2.1 | 6.3 | 162 | 31.56 | 3.546 |
| 35 | 34.36 | 7 | 2.5 | 7.5 | 229 | 44.72 | 2.499 |
| 50 | 49.48 | 7 | 3 | 9 | 330 | 64.4 | 1.736 |
| 70 | 65.81 | 19 | 2.1 | 10.5 | 441 | 85.65 | 1.313 |
| 95 | 93.27 | 19 | 2.5 | 12.5 | 626 | 121.39 | 0.925 |
| 120 | 116.99 | 19 | 2.8 | 14 | 785 | 152.26 | 0.737 |
| 150 | 147.11 | 37 | 2.25 | 15.7 | 990 | 191.46 | 0.587 |
| 185 | 181.62 | 37 | 2.5 | 17.5 | 1221 | 236.38 | 0.476 |
| 240 | 242.54 | 61 | 2.25 | 20.2 | 1635 | 299.05 | 0.357 |
| 300 | 299.43 | 61 | 2.5 | 22.5 | 2017 | 369.2 | 0.289 |
| Class | 20SA | 27SA | 30SA | 40SA | ||||||||
| Type | A | B | – | – | – | |||||||
| Tolerance on diameter | Ø ≥ 2,67 mm | ± 1,5% | ± 1,5% | ± 1,5% | ± 1,5% | ± 1,5% | ||||||
| Ø < 2,67 mm | ± 0,04 mm | ± 0,04 mm | ± 0,04 mm | ± 0,04 mm | ± 0,04 mm | |||||||
| Minimum thickness of aluminium clad (% of radius) | 8% if Ø < 1,80 mm | 14% | 15% | 25% | ||||||||
| 10% if Ø ≥ 1,80 mm | ||||||||||||
| Nominal density at 20°C (g/cm³) | 6,59 | 6,53 | 5,91 | 5,61 | 4,64 | |||||||
| Resistivity at 20°C max. (nΩ x m) | 84,80 | 84,80 | 63,86 | 57,47 | 43,10 | |||||||
| Conductivity (IACS) | 20,3% | 20,3% | 27% | 30% | 40% | |||||||
| Final modulus of elasticity (GPa) | 162 | 155 | 140 | 132 | 109 | |||||||
| Coefficient of linear expansion (K-1) | 13,0 x 10-6 | 12,6 x 10-6 | 13,4 x 10-6 | 13,8 x 10-6 | 15,5 x 10-6 | |||||||
| Constant-mass temperature coefficient of resistance (K-1) | 0,0036 | 0,0036 | 0,0036 | 0,0038 | 0,0040 | |||||||
| MECHANICAL PROPERTIES | ||||||||||||
| class | type | nominal diameter (mm) | min. tensile strength (N/mm²) | min. stress at 1% extension | elongation | torsion test (min. twists) | ||||||
| 20SA | A | 1,24 | 3,25 | 1340 | 1200 | 1,5% | 20 | |||||
| 3,26 | 3,45 | 1310 | 1180 | |||||||||
| 3,46 | 3,65 | 1270 | 1140 | |||||||||
| 3,66 | 3,95 | 1250 | 1100 | |||||||||
| 3,96 | 4,10 | 1210 | 1100 | |||||||||
| 4,11 | 4,40 | 1180 | 1070 | |||||||||
| 4,41 | 4,60 | 1140 | 1030 | |||||||||
| 4,61 | 4,75 | 1100 | 1000 | |||||||||
| 4,76 | 5,50 | 1070 | 1000 | |||||||||
| B | 1,24 | 5,50 | 1320 | 1100 | ||||||||
| 27SA | – | 2,50 | 5,00 | 1080 | 800 | |||||||
| 30SA | – | 2,50 | 5,00 | 880 | 650 | |||||||
| 40SA | – | 2,50 | 5,00 | 680 | 500 | |||||||
| Diameter | Cross Section(㎜²) | Unit Length Weight(kg/km) | Min Breaking Load(kN) | Min Tensile Strength (Mpa) | Resistance at 20℃ ㎜ ²/m≤ | ||
| Nominal | Max | Min | |||||
| 2.75 | 2.791 | 2.709 | 5.94 | 39.1 | 7.96 | 1340 | 14.3 |
| 3 | 3.045 | 2.995 | 7.069 | 46.6 | 9.47 | 1340 | 12 |
| 3.25 | 3.299 | 3.201 | 8.296 | 54.7 | 11.1 | 1340 | 10.2 |
| 3.75 | 3.806 | 3.694 | 11.04 | 72.8 | 13.8 | 1250 | 7.7 |
| 4.25 | 4.313 | 4.186 | 14.19 | 93.5 | 16.7 | 1180 | 5.98 |
| Nominal Diameter | Calculated Cross Section Area(㎜²) | Min Tensile Strength (Mpa) | Calculated Breaking Load (KN) | Min Coating Thickness | DC Resistance at 20℃ ㎜² /m≤ | Weight (kg/km) | |
| mm | AWG | ||||||
| 2.052 | 12 | 3.307 | 1340 | 4.45 | 0.103 | 25.64 | 21.8 |
| 2.304 | 11 | 4.169 | 1340 | 5.61 | 0.115 | 20.34 | 27.49 |
| 2.589 | 10 | 5.26 | 1340 | 7.07 | 0.13 | 16.12 | 34.66 |
| 2.904 | 9 | 6.633 | 1340 | 8.92 | 0.145 | 12.78 | 43.65 |
| 3.264 | 8 | 8.367 | 1340 | 11.2 | 0.163 | 10.14 | 55.14 |
| 3.477 | 7 | 9.495 | 1310 | 12.4 | 0.174 | 8.93 | 62.57 |
| 3.665 | 7 | 10.55 | 1280 | 13.5 | 0.183 | 8.04 | 69.48 |
| 3.934 | 6 | 12.16 | 1240 | 15.1 | 0.197 | 6.93 | 80.13 |
| 4.115 | 6 | 13.3 | 1210 | 16 | 0.206 | 6.38 | 87.62 |
| 4.392 | 5 | 15.15 | 1170 | 17.7 | 0.22 | 5.6 | 99.84 |
| 4.62 | 5 | 16.76 | 1140 | 19.1 | 0.231 | 5.06 | 110.5 |
| 4.775 | 4 | 17.91 | 1100 | 19.7 | 0.239 | 4.73 | 118 |
| 5.189 | 4 | 21.15 | 1070 | 22.6 | 0.259 | 4.01 | 139.34 |
| Nominal Diameter, in./mm | Size, AWG | 20.3% | 27% | 30% | 40% | |||||
| psi | MPa | psi | MPa | psi | MPa | psi | MPa | |||
| 0.2043 | 5.19 | 4 | 155 000 | 1070 | 125 000 | 862 | 102 000 | 703 | 80 000 | 552 |
| 0.1880 | 4.78 | 160 000 | 1100 | 129 000 | 889 | 106 000 | 731 | 84 000 | 579 | |
| 0.1819 | 4.62 | 5 | 165 000 | 1140 | 133 000 | 917 | 110 000 | 758 | 88 000 | 607 |
| 0.1729 | 4.39 | 170 000 | 1170 | 137 000 | 945 | 114 000 | 786 | 92 000 | 634 | |
| 0.1620 | 4.11 | 6 | 175 000 | 1210 | 141 000 | 972 | 114 000 | 786 | 96 000 | 662 |
| 0.1549 | 3.93 | 180 000 | 1240 | 145 000 | 1000 | 118 000 | 814 | 96 000 | 662 | |
| 0.1443 | 3.67 | 7 | 185 000 | 1280 | 150 000 | 1034 | 122 000 | 841 | 98 000 | 676 |
| 0.1369 | 3.48 | 190 000 | 1310 | 154 000 | 1062 | 126 000 | 869 | 98 000 | 676 | |
| 0.1285 | 3.26 | 8 | 195 000 | 1340 | 156 000 | 1076 | 128 000 | 883 | 99 500 | 686 |
| 0.1144 | 3.91 | 9 | 195 000 | 1340 | 156 000 | 1076 | 128 000 | 883 | 99 500 | 686 |
| 0.1019 | 2.59 | 10 | 195 000 | 1340 | 156 000 | 1076 | 128 000 | 883 | 99 500 | 686 |
| 0.0907 | 2.30 | 11 | 195 000 | 1340 | 156 000 | 1076 | 128 000 | 883 | 99 500 | 686 |
| 0.0808 | 2.05 | 12 | 195 000 | 1340 | 156 000 | 1076 | 128 000 | 883 | 99 500 | 686 |
